SP7282 (15W, 5-9V, + or -200V )

Standard Model Number: SP7282

RoHs Model Number : SP7282/Y
Standard Model is NOT RoHs Compliant

Beschreibung

Input Voltage ……………………………………………………… 5-9Vdc

Output Voltage …………………………………………………… 200Vdc

Output Current ……………………………………………………… 75mA

Voltage Accuracy …………………………………………………. +/- 1%

Line Regulation …………………………………………………. +/- 0.1%

Load Regulation ………………………………………………… +/- 0.2%

Output Ripple ……………………………………………….. < 0.4% P-P

Input Filter ……………………………………….. Low ESR Capacitor

Efficiency ………………………………………………………. 82% (typ.)

Short Circuit Protection ………………………………….. Continuous

Switching Frequency ………………………………………….. 130 kHz

Output Isolation ……………………………………………….. 1000 Vdc

Input / Output Capacitance ……………………………………. < 80pF
