ELECTRICAL SPECIFICATIONS
Output Ripple< 0.3% P-P
| Input Voltage | 9V – 36Vdc |
| Output Voltage #1 | 150 Vdc |
| Output Voltage #2 | 66 mA |
| Output Current #1 | 66 mA |
| Output Current #2 | 66 mA |
| Voltage Accuracy | < 3% |
| Line Regulation | < 3% |
| Load Regulation | < 3% |
| Input Filter | Pi Network |
| Efficiency | 85% (typ.) |
| Short Circuit Protection | Continuous |
| Switching Frequency | 100 kHz |
| Isolation | 1000 Vdc |
| On/Off | ON=N.C. or 0Vdc / OFF=5Vdc |
