SP7278 (10W, 0-24, + or-6250V, Metal case-Shield )
Standard Model Number: SP7278
RoHs Model Number : SP7278/Y
Standard Model is NOT RoHs Compliant
Categories: Designation number, Output power, Output voltage
- Description
Description
Description
ELECTRICAL SPECIFICATIONS
Input Voltage ……………………………………………………….. 24Vdc
No Load Input Current …………………………………………<230 mA
Full Load Input Current ………………………………………. <900mA
Output Voltage ……………………………………………….. +6250Vdc
Output Current ……………………………………………………. 1.6 mA
Voltage Accuracy …………………………………………………. +/- 4%
Line Regulation ………………………………………….. Proportional
Load Regulation …………………………………………………. +/- 20%
Output Ripple ……………………………………………… < 0.25% P-P
Input Filter …………………………………………………… LC Network
Efficiency ……………………………………………………………. > 70%
Short Circuit Protection ………………………………….. Continuous
Switching Frequency ……………………………………………. 80 kHz
Output Isolation …………………………………………………. 500 Vdc
Input / Output Capacitance ……………………………………. < 30pF
