P10 SERIES (10W)
Features
- Customer Selects Output Voltage
- Outputs to 8000 Vdc
- Proportional Output Voltage
- Six-Sided Shielded Case
- 60 kHz Switching Frequency
- 5000 Vdc Output Isolation
- Continuous Short Circuit Protection
The P10 Series of DC/DC converters offer a 5000 Vdc isolated high voltage output directly proportional to input voltage. All models will tolerate a short circuit indefinitely. They also include a Pi Network input filter to minimize reflected ripple current.
Beschreibung
Beschreibung
| Output Power | 10W |
| Output Voltage | +or- 33Vdc up to +or- 8kVdc |
| Output Ripple | <0.3% P-P |
| Input Filter | Pi Network |
| Short Circuit Protection | Continuous |
| Output Isolation | 5000Vdc |
| Temp. (Operating, Case) | -25 to +85°C |
| EMI/RFI | Six Sided Shield |
| Case Material | Nickel Plated Metal |
